Qubo F800 Mobile Welding Fume Extractor 1500 Diesel With Replacement Prefilter Hose

Qubo F800 Mobile Welding Fume Extractor 1500 Diesel With Replacement Prefilter Hose

Qubo F800 Mobile Welding Fume Extractor 1500 Diesel With Replacement Prefilter Hose
Qubo F800 Mobile Welding Fume Extractor 1500 Diesel With Replacement Prefilter Hose
Qubo F800 Mobile Welding Fume Extractor 1500 Diesel With Replacement Prefilter Hose
Product Details:
Place of Origin: China
Brand Name: Fumego Qubo
Certification: CE ROHS
Model Number: FL700
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Carton box package
Delivery Time: 5-8 days
Payment Terms: T/T, Western Union
Supply Ability: 100pcs per week
Contact Now
Detailed Product Description
Product Name: Laser Fume Extractor Weight: 76 Kg
Air Volume: 1000 M³/h After Sales: Online Support
Power: 700W Noise: 70 Db
Voltage: 110/220 V Warrenty: 2 Years
Usage: Laser Cutting Marking Welding Control: Remote And Touch Screen
High Light:

1000m3/h Mobile Welding Fume Extractor

,

700W Mobile Welding Fume Extractor

,

Replacement Prefilter Hose Laboratory Fume Extractor

Qubo F800 Mobile Welding Fume Extracctor 1500 Diesel For Fiber Laser With Replacement Prefilter Hose







Advantages:



1, The fans material is special alloy, which can avoid corrosion;

The fans runs very stable and reliable, very big air flow;

2, Saving energy and cost, lower noise and larger suction power;

3, Our machine can maximize to use the filters;

We are using different layers filters to collect different size level of pollution.

4, Using noise reduction structure design, to keep working environment quiet;

5, The filter element adopts a return structure and can hold dust on all sides;

6, The fan speed is adjustable, timing function to turn on and off, and remote control;



Instructions:



Modle FL-300 FL-500 FL-700
Filter 3 Layers 5 Layers 6 Layers
Weight 36.7kg 60kg 70kg

Dimensions

(L*W*H)

425*315*700mm 550*440*885mm 550*440*1035mm
Air Flow 450m³/h 700m³/h 750m³/h
Noise <59dB <70dB <75dB
Power 330W 450W 700W
Voltage AC 110-220V AC 110-220V AC 110-220V
Size of Filter (can be customized)

Fireproof

protection net

No 415*335*25mm 415*335*25mm
Primarry filter 450*380*100mm 450*380*100mm 450*380*100mm
PP Medium filter 450*380*50mm 450*380*50mm 450*380*50mm
Glass fiber filter No No 450*380*100mm

Activated carbon

filter

450*380*50mm 450*380*50mm*2 450*380*50mm*2





Features:



1, It is also a dust collector, bad smell remover, and fire proof;

We have a fire proof frame screen, bellows pocket to collect dust, and PP HEPA filter and active carbon filters to remove bad gas.

2, All mental material shell, durable and sturdy;

3, Pre-filter, Middle filter and high efficient filter can be replaced independently, very convenient and easy to do the replace job.

4, The machine is in a very small dimension, never occupying space;

5, No need to assemble, plug and turn it on, start to work;



FAQ:



Q: What should we do if the suction power cant clean all smoke?

A: Check the distance of the air input and smoke produced place, air flow near, length and diameter of the tube.

Q: Do you do OEM?

A: Yes

Q: What is the main parts of the machine?

A: Motor, control parts, Power source, Main body shell, tube, Smoke cover and filters etc.

Q: Where is your factory?

A: We have 2 manufacture plant, in Shenzhen and Dongguan, have more than 500 workers.

Q: What is the difference between fume extractor and air purifier?

A: The working princeple is closed, But application is different. Fume extractor is more professional in clean fume, dust and bad smells.



Picture:



Qubo F800 Mobile Welding Fume Extractor 1500 Diesel With Replacement Prefilter Hose 0
