| Place of Origin: | China |
| Brand Name: | Fumego |
| Certification: | CE ROHS |
| Model Number: | FL-700 |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton box package |
| Delivery Time: | 5-8 days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100pcs per week |
| After-sales Service Provided: | Online Support | Power: | 700 W |
|---|---|---|---|
| Noise: | 70 Db | Warranty: | 2 Years |
| Voltage: | 110/220 V | Application: | SMT, Wave-soldering, Big Laser Cutting, Welding Plant |
| Weight: | 70 KG | Color: | White And Mental Shell |
| High Light: | 700W Explosion Proof Dust Collector,Wave Soldering Explosion Proof Dust Collector |
||
Smoke Purification Absorber Solder Fume Extractors With 7 Layers Filters
Instructions:
1, We are using HEPA h13 degree filters, 0.3 um pollution items filter rate is 99.99%;
2, Pre-filter, Middle filter and high efficient filter can be replaced independently, very convenient and easy to do the replace job.
3, Our machine can maximize to use the filters;
We are using different layers filters to collect different size level of pollution;
4, The fume tube can be randomly rotate, and can be fix in any position;
We using bamboo shape tube and 360°rotation support tube, to make the machine position very flexible during work.
5, Microcomputer chip control, digital display, and remote control;
Our machine have a very good outlooking, we have digital display, and can be controlled by touch screen and can be remote in a distance.
Specifications:
| Modle | FL-300 | FL-500 | FL-700 |
| Filter | 3 Layers | 5 Layers | 6 Layers |
| Weight | 36.7kg | 60kg | 70kg |
|
Dimensions (L*W*H) |
425*315*700mm | 550*440*885mm | 550*440*1035mm |
| Air Flow | 450m³/h | 700m³/h | 750m³/h |
| Noise | <59dB | <70dB | <75dB |
| Power | 330W | 450W | 700W |
| Voltage | AC 110-220V | AC 110-220V | AC 110-220V |
| Size of Filter (can be customized) | |||
|
Fireproof protection net |
No | 415*335*25mm | 415*335*25mm |
| Primarry filter | 450*380*100mm | 450*380*100mm | 450*380*100mm |
| PP Medium filter | 450*380*50mm | 450*380*50mm | 450*380*50mm |
| Glass fiber filter | No | No | 450*380*100mm |
|
Activated carbon filter |
450*380*50mm | 450*380*50mm*2 | 450*380*50mm*2 |
Advantages:
1, The machine is in a very small dimension, never occupying space;
2, Imported integrated AC fan, stable performance and longer life;
3, There is a watch window, from which we can easily notice the filter situation and whether it should be replaced or not;
4, It will alarm when the filters is out of service;
People can be easily know when to replace filters and any problem happened if the machine is out of work.
5, The filter element adopts a return structure and can hold dust on all sides;
FAQ:
Q: What should we do if the suction power can’t clean all smoke?
A: Check the distance of the air input and smoke produced place, air flow near, length and diameter of the tube.
Q: Do you do OEM?
A: Yes
Q: What is the main parts of the machine?
A: Motor, control parts, Power source, Main body shell, tube, Smoke cover and filters etc.
Q: Why should we use fume extractor?
A: There are so many advantages for fume extractor, save cost, convenient to use, air clean efficiency, keep your staff heathy and so on.
Q: How long should we clean the tube?
A: It depends on the real situation of the tube, need to inspection every week.
Q: How long is needed for manufacture?
A: It always be about 3-7days, big quantity need to discuss.
